Kenmore Range and Wall Oven Codes Across Control Platforms

Kenmore Range and Wall Oven Error Codes for San Diego Homes

Kenmore ranges and wall ovens use several control platforms, so the same fault category may appear as a three-digit code, a four-digit code, or a combined F/E message. This list includes codes used on 790-series four-digit controls, glass-touch ranges, 665-series models, and other Kenmore ovens. Always confirm the complete model number before ordering parts or following a model-specific reset.

An error code identifies the system that detected a problem, but it does not always prove that one component has failed. A control-board message may also involve wiring or an attached component, while a sensor code can result from the sensor, its harness, or the electronic control.

Four-Digit Control and Temperature Codes

F001, F002, F004, and F005 identify a touch-panel failure. F003 and F013 point to the oven user-interface control board, while F015 indicates another touch-panel fault. F017 means the interface board cannot configure the touch panel, often because of damaged wiring, incompatible replacement parts, or a failed control. F018 identifies a relay-control-board failure.

F010 is a runaway-temperature warning. The oven temperature is above approximately 600°F and continues rising. Disconnect power and allow the appliance to cool. The temperature sensor and relay control should be tested before the oven is used again.

F011 means a keypad button has remained active for about 30 seconds. Remove anything pressing against the controls and press Stop once. If the message returns, the touch panel, wiring, or user-interface board may require diagnosis.

F030 and F031 indicate an oven-temperature-sensor failure. The sensor, harness, connections, and control input may need testing. These four-digit codes should not be confused with shorter F30/F31 displays from another Kenmore platform, although both groups involve oven-temperature sensing.

Four-Digit Door and Lock Errors

F050 means the relay board cannot confirm the status of the oven door switch or lock switches. F090 appears when the control does not detect the door-lock motor operating. F095 means the lock motor does not stop when expected.

These messages commonly affect Oven Lockout or Self Clean. Let the oven cool fully and never force the door. The lock assembly, switches, wiring harness, or relay control board may be responsible.

Glass-Touch Range Error Codes

On compatible Kenmore glass-touch ranges, F10 also indicates runaway temperature or an inaccurate temperature-sensor signal. F11 identifies a defective glass-touch panel.

Codes F12, F13, F15, F16, F17, F18, and LinE ERR indicate an electronic oven-control-board failure. A 30-second power interruption may clear a temporary control problem, but a returning message means the electronics still require diagnosis.

F20 means the oven control is not communicating correctly with the surface-burner control system. F23 and F24 identify communication failure between the oven control and convection-fan speed control board. These faults may involve control boards, harnesses, connectors, or related cooktop and fan components.

F30 and F31 point to an oven-temperature-sensor circuit failure. F90, F91, F92, F93, F94, and F95 belong to the oven door-lock system. If the oven remains locked after cooling, keep it disconnected rather than pulling on the door.

F/E Codes on 665-Series and Related Models

On compatible Kenmore ranges and wall ovens, F1 means the electronic oven control has failed. F2/E0 indicates a disconnected keypad harness. F2/E5 or F2/E6 means the Cancel key is defective. These codes may require inspection of the keypad, harness, and electronic oven control.

F3/E0 identifies an open oven-temperature-sensor circuit, while F3/E1 identifies a shorted sensor circuit. A technician should check sensor resistance, wiring continuity, connectors, and the electronic control before deciding which part needs replacement.

F9: Model-Dependent Door-Lock Fault

On many Kenmore self-cleaning ranges, F9 indicates an oven door-lock failure. The exact interpretation can vary by model family, but the code commonly involves the latch assembly, door switches, wiring, or electronic control. Allow the appliance to cool and do not force a locked door.

Safe First Response to a Kenmore Oven Code

Record the exact code and what the oven was doing when it appeared. Turn off power if the oven overheats, produces smoke or a burning odor, sparks, or keeps operating after being canceled. One brief reset may clear a temporary interruption, but repeated resets are not a repair.

Reset Appliance Repair provides Kenmore range and wall oven diagnostics in San Diego for touch-panel failures, control-board faults, overheating, temperature-sensor errors, communication problems, and door-lock malfunctions.
